530 Vertical Reflow Oven 5 Temp. Zones (upper3+ bottom 2) 1000*300mm
Smt Reflow Soldering Machine Lead-free
1.Competitive price for quality
2. More than 10 years manufacturing experience
3.One of the Leader of Smt machine manufacurers in China
530 reflow oven SPECIFICATION:
• The heating system is unique, advanced and long-life.
• High efficiency and energy-save nickel cauterize heating pipe is
used in heating system, strong hot air cycle structure , making PCB
and components heating equally, high efficiency and rapid heating
speed.
• The intelligent micro-computer precision controller, through
intelligent operation of PID, control heating automatically ,
temperature controlling function can detect the changing of
temperature, and then make inner temperature stable by controlling.
Modular design , easy to repair and assembly.
• Import high temperature and high speed motor are used, stable
operation,small tremble and low noise.The efficiency be improved
greatly, extending the using time. The heating system use import
components to make sure high stability and reliability of all
system.
• Reliable and stable transmission system, stable operation driver,
and the speed range is 0-2000mm/min.
• Stable operation special stainless steel net chain is durable and
wearable. So it didn’t need to be change for a long time that can
save cost.
• Stable and reliable electronic controller system.
| Model No. | 530 |
| Number of Heating Zones | Up 3 + Bottom 2 |
| Length of Heating Zones | 1000mm |
| Heating Pattern | Up: Hot air; Bottom: Hot air (Forced convection of hot air, Taiwan SAYA motor) |
| Number of Cooling Zones | 2 Plasma DC Fan |
| Max.Width Of PCB | 300mm (stainless steel mesh belt) |
| Conveyor Direction | L→R |
| Conveyor Height | 880±20mm |
| Transport Mode | Mesh Belt |
| Conveyor Speed Range | 0-2200mm/min |
| Power Supply | 5 Wire, 3 Phase, 380V 50/60Hz |
| Start Power | 7KW |
| Power Consumption | Approx 1.5KW |
| Warming Time | Approx 15-20 mins |
| Temp. Setting Range | Room Temp.- 380℃ |
| Temperature Control Method | Instrument-controlled |
| Temperature Difference Between Adjacent Zone | 70 ℃, can correspond to the highest standards of lead-free process. |
| Temperature Control Precision | ±2℃ |
| Temperature Deviation on PCB | ±2℃ |
| Abnormal Alarm | Temperature abnormal (too high or too low after the constant temperature keeping) |
| Open Way | Manual |
| Dimension(L*W*H)mm | 2000*612*1450MM |
| Weight | Approx200Kg |
Pictures as follows:
Warranty:
The complete machine has a warranty period of 1 year from the time
of purchase and lifetime service.
We always provide spare parts of machine, factory reliable direct
supply.
We provide online Q/A and troubleshooting support and technical
advice service.
Provide one to one after-sale service. Each machine 100% tested well before ship out.
