    Hottest CHMT48VB 58 Feeders + Dual Vision Camera Desktop Pick and Place Machine

    Ask Lasest Price
    Brand Name : Charmhigh
    Model Number : CHMT48VB
    Certification : CE
    Price : $5180
    Payment Terms : T/T, Western Union
    Supply Ability : 200 Per month
    Delivery Time : 1-2 days
    • Product Details
    • Company Profile

    Hottest CHMT48VB 58 Feeders + Dual Vision Camera Desktop Pick and Place Machine

    CHMT48VB Double Stack 58pcs Feeders Charmhigh Benchtop

    Advanced Pick and Place Machine​ 110v 220V English Version CE Passed

    Specifications of CHMT48VB:

    Machine is completed, ready for work, each machine will be 100% tested well, QC passed.
    Please purchase it with confidence.
    Quality guarantee, quality is better than other brand machines.
    HS CODE: 8479896200 , pick and place machine


    Description:

    This CHMT48VB is an update version of CHMT48VA, which included dual side feeders with total 58pcs (left 29pcs + right 29pcs).

    The operation system is the same as CHMT48VA and it can install more different kinds of materials, using 502---507 different kinds of Juki nozzles, suitable for 0402,0603,0805-5050, SOP,QFN,LQFP144,Diode,Transistor,BGA...etc, which can meet more customers' demand.

    PayPal also accepted, our PayPal account is: sales@charmhigh-tech.com

    Paypal link: paypal.me/Charmhigh


    CHMT48VB Working video:
    www.youtube.com/watch?v=YjPGfoU1Ijo


    CHMT48VB placing IC:
    www.youtube.com/watch?v=I-g8x98jmz0


    ModelCHM-T48VB
    PCB area10mm*10mm - 355mm*355mm
    X Y axis Travel420*460mm
    Z axis moving range15mm
    Placement heads2pcs
    Feeders

    Left 29pcs + right 29pcs

    8mm=44pcs, 12mm=8pcs, 16mm=4pcs, 24mm=2pcs,

    Front IC stack=14pcs, user-defined IC tray

    Vision systemDual cameras (up & down cameras)
    DriveClosed-loop control stepper servo drive system, make sure never lose step
    Z axis self-return detectionYes, prevent nozzles breaking
    Pull pin self-returnYes
    Leakage of material detection methodVacuum detection, vision detection
    Touch screen7”industry touch screen
    Main boardIndependent research industry main board
    SystemEmbedded Linux system
    Mounting speed5000cph (vision off); 3000cph (vision on)
    Mounting precision±0.025mm
    Components0402-5050,SOP,QFN (tape width: 8MM,12MM,16MM,24MM)
    Machine dimensionL 960mm* W 705mm* H 335mm
    Vacuum pump-92KPA (2pcs,build-in, mute type)
    External air sourceNo need (machine build-in mute vacuum pump 2pcs)
    External PCNo need
    Voltage220V (110V), 50Hz
    Net weight75kg
    Gross weight86kg / 116*81*52cm ---- wooden packing

    Competitive Advantage:

    1. Convenient software, Embedded Linux System of the machine, stable industry main board, independent operation, no need external computer, operation easier and more convenient, learn fast.
    2. In-build touch screen, no need external monitor, room saved, more convenient operation, USB mouse supported as well.
    3. Top and bottom two vision cameras, correct the position of each components, you can view the vision image from screen for every components.(max component size 22*22mm)
    4. It has flexible PCB clamping fixture, suitable for different size of PCB.
    5. It supported custom IC tray, IC tray can be fixed on machine table.
    6. Two mounting heads with 2pcs Juki Nozzles, Juki nozzle inside magnet, so it can be removed by finger, no need to disassemble with wrench, nozzles rotation angle -180 degree to +180 degree.
    7. All-in-one machine, 29pcs feeders included in machine, no need to buy other parts, machine is ready to work.
    8. Z axis detection, machine's pull needle automatically return to origin to avoid nozzles broken.

    9. Max height component support 5mm.
    10. Closed-loop control, X,Y Axis with encoder, not out of step.
    11. PCB calibrated by two components position, then rest components will be calibrated automatically.
    12. Auto calibrate mark 2 points, it will be auto calibration before every running, make sure every PCB mounting precisely.
    13. With vacuum detection, with automatic feeding, if one component suck crooked, it will automatically throw it to deposit area, then pick a new one to mount again.

    14. With vision detection, camera will auto correction component angle and place on PCB board right place. If heads not picking up components, camera will detect it and go back to pick again, 3 times not picking, machine will alarm and stop, after supply material, then continue working, no need to start over again.

    15. Comes with convert tool (PC version), edit work file in computer and load work file into machine by USB port, quick and convenient.
    16. Support panelized boards.
    17. If you don't have PCB file, you can create a new work file to program in machine directly.

    18. Support single step.

    19. Support cut tapes/ bulk material/ tube material.


    Why choose Charmhigh?
    1.Professional desgin and room saved.
    2.User friendly operation, no need professional SMT engineer, entry-level device
    3.One machine - Integrated operation, no need extra pump or PC or any supporting facility
    4.High accuracy and reliability,make up the defection of manual work
    5.Cost efficient, reduce expense to own a professional automatic SMT production line
    6.International express with door to door service,3-5 working days delivery
    7.Especial for laboratory research and development,samples,to avoid any patents and designs revealment.

    8.One machine equal to 5 soldering staff, easy manage and cost-saved. Good for small batch production.

    9.Charmhigh Is factory supply, all of our machines parts are researched and manufacturing by ourselves. After-service spare parts never stop.

    10. Charmhigh is a professional manufacturer of SMT Pick and Place machine since 2009. All the software are researched by ourselves.


    Standard Accessories for CHMT48VB:

    1) Pick and Place Machine CHMT48VB 1
    2) Juki nozzle total 4pcs (503, 504, 505, 506 size)
    3) 8G USB driver 1
    4) Power Cord 1
    5) Pull needle 2
    6) Coil for pull pin1
    7) Camera positioning adjust black board 1
    8) Hex wrench 6
    9) Tweezers 1
    10) Brush 1
    11) Pen for touch screen 1
    12) Fixture for IC tray 4
    13) Grease 1
    14) English user manual 1



    Kindly note:
    The pick and place machine is complete set with all accessories included in the package, QC passed.
    It is all-in-one machine, ready to use!
    You can use it when you receive it. Good after-sale tech support, please purchase it with confidence.
    Enjoy with your pick and place machine!


    Warranty:
    The complete machine has a warranty period of 1 year from the time of purchase and lifetime service.
    We always provide spare parts of machine, factory reliable direct supply.
    We provide online Q/A and troubleshooting support and technical advice service.

    Provide one to one after-sale service. Each machine 100% tested well before ship out.
