Updated CHMT48VA SMT Automatic Pick Place Machine with Vision System Linux Computer​ 110v 220v


SMT Small Desktop Pick and place machine CE passed, We can ship to Europe Countries!

Accoding to Customer requirement, we update the machine and software continuously, CHMT48V updated to CHMT48VA model, machine in very good and stable condition, we can promise you a best machine!

Competitive Advantage:

1. Convenient system, Embedded Linux System of the machine, very stable and fast speed, independent operation, no need external computer, operation more easy and convenient.
2. Industry touch screen, more stable, quality higher. It can connect a external USB mouse on the usb port to operate the machine like a computer.
3. Top and bottom two cameras correct the position of each components very accurate, especially for IC.
4. It has flexible PCB clamping fixture, user-defined from stack NO.80. convenient and quick.
5. The vision also can second correction machine origin point, make sure origin point correct.
6. With two nozzles placing heads, high precise Juki Nozzles with magnet, no need to disassemble with wrench. 2 nozzles arbitrary rotation angle -180 degree~ +180 degree. Placing height can adjustable, accuracy of 0.1 mm.

7. Pull pin automatically return to avoid nozzles broken, pull pin not be stuck, big progress.

8. Z axis detection, placement head can auto back to origin.

9. Updated stepper motor, never loose steps.
7. PCB by two visual calibration, first and last componet, amend the offset of PCB.
8. Calibration can be rapidly and accurately for PCB, do not need to care about offset, no need to calculate the input.
9. Comes vacuum testing, with automatic feeding; if one component suck crooked, it will automatically throw it to the feed zone, then pick a new one to mount again.
10. If lack material it will automatic detection, then alarm; after supply the material then continue working, no need to re-start.
11. Support any number of PCB batch.
12. If no PCB file, or don’t use protell software, you can creat a new file to program. Support single step.

Specifications of CHMT48VA:

Description:

SMT (surface mount technology) component placement systems, commonly called pick-and place

machines or P&Ps, are roboticmachines which are used to place surface mount devices (SMDs) onto a printed circuit board (PCB). They are used for high speed, high precision

placing of broad range of electronic components, like capacitors, resistors, integrated circuits onto the

PCBs which are in turn used in computers, consumer electronics as well as industrial, medical, automotive,

military and telecommunications equipment.

The new vison system CHMT48VA is independent product of Charmhigh, updated from CHMT48V Model in 2015 October, with advanced technology in China, specail for research Lab, medium enterprise, Electronics

enthusiasts or enterpreneur etc. It is small with high precision, accurate positioning, easy operation with

stable performance. Now leading the technology in China.
CHMT48VA feedback very well. Compare with previous model CHMT28,CHMT36, CHMT48V it has a lot of
improvement, in 2015, CHMT48V updated to CHMT48VA, more stable and longer lifetime, to meet each customer's demand, here are some highlights as follows:

Applications industry:

Household appliances industry, Auto electronics industry, Power industry, LED industry, security,instruments and meters industry, communications industry, intelligent control industry, Internet of Things(IOT) industry and military industry, etc.


Standard Accessories for CHMT48V:

1) Pick and Place MachineCHMT48VA: 1
2) Juki nozzle: Totally 4pcs (503, 504, 505, 506 size)
3) 8G USB flash 1
4) Power Cord: 1
5) Pull pins: 2
6) Coil for pull pin:1
7) Camera positioning adjust black board: 1
8) Hex wrench: 6
9) Tweezers: 1
10) Brush: 1
11) English user manual: 1

Detail pictures:

User-defined IC tray, very convenient:

A closed-loop servo high-pressure stepper motor system, ensure never loose steps:

Top and Bottom camera, make sure each component place very accurate:

Camera side:

Very safe packing: (All are real Pictures)

Samples:

IC Perfect!

Q1: What is the lead time of your products? (How long do you need to prepare my goods?)

A: 2-3 days for 1-3 unit machine. 5-15 days for mass production orders (based on different quantities).

Q2: How will you deliver my goods to me?

A: We usually ship by international expresses such as DHL,UPS, FedEx, TNT to enable our customers get

their goods rapidly. For bigger quantity, ship by air or by sea.

Q3: How long do I need to wait before my goods arrive?

A: 3-7 days for international express. 5-8 days for air transportation. 20-40 days for sea transportation.

Q4: What is your product quality?

A: Our raw materials are purchased from qualified suppliers, the best qaulity in China. And our engineers all have over 20 years expereinces in Machinery, ensure good quality and functions. Now CharmHigh's Quality and feedback is better than other brands in China.

Warranty:

The complete machine has a warranty period of 1 year from the time of purchase and lifelong service
support as well as a long term factory price supply. (Artificial damage except)
We provide online Q/A and troubleshooting support and technical advice service. Provide one to one

after-sale service.

If your machine or machine part is defect on transportation, please take photos and send to our email, we will make placement of damaged parts to you soon.

Each machine 100% test well before ship out.
